Seg WI Series Reference Manual

Prot . Def. Autom. Reset [Device Para / Reset]
New Pickup or After 8 h OFF (=No Autom. Reset) . . . New Pickup or After 10 s
╚═▷ Def. Autom. Reset
P.1
The automatic reset will reset all latched LEDs, all DiggiMEC Flag Indicators, and a fault/trip info that might be visible
on the DiggiMEC display. This is done depending on this setting, when a new protection pickup occurs or after a
particular time has elapsed.
Prot . Meth.Detect.Bkr.Pos. [Protection Para / Breaker & Trip]
Current-Based If: Device Variant/Inputs = Without Inputs
• Current-Based•
If: Device Variant/Inputs = Without Inputs
• Current-Based•
If: Device Variant/Inputs = Ext. Trip
•
Current-Based
•
If: Device Variant/Inputs = Ext. Trip, Ext. Reset
•
Current-Based
•
If: Device Variant/Inputs = Con󰊟gurable
• Current-Based•
If: Device Variant/Inputs = Con󰊟gurable Inputs
•
Current-Based, Aux-Based, Current and Aux
•
╚═▷ Meth.Detect.Bkr.Pos.
P.1
Select the method to be used to determine the connected breaker position.
Prot . I ON [Protection Para / Breaker & Trip]
0.10In
Only available if:
• Prot . Meth.Detect.Bkr.Pos. = Current-•
Based
• Prot . Meth.Detect.Bkr.Pos. = Current•
and Aux
0.05In . . . 0.20In P.1
The breaker is determined as ON (closed) based on current measurement if any phase current is greater than this
value (for at least the settable duration »t ON/OFF«).
Prot . Aux ON [Protection Para / Breaker & Trip]
Only available if:
• Prot . Meth.Detect.Bkr.Pos. = Aux-Based•
• Prot . Meth.Detect.Bkr.Pos. = Current•
and Aux
If: Device Variant/Inputs = Without Inputs
• “-”•
• “-”•
• “-”•
• “-”•
•
“-”
•
• “-”, Prot . DI 1, Prot . DI 2•
P.1
39WIC1WIC1-2.0-EN-REF
9 Protection Parameter
9.2 Prot: Settings
