Color Description
Green Green = “active” color (if the assigned signal is active)
Green / Red Green = “active” color (if the assigned signal is active), red = “inactive” color (if the
assigned signal is inactive)
Selection list referenced by the following parameters:
•
╚═▷ Prot . Assign Ext. Reset
•
• ╚═▷ Prot . Aux ON•
• ╚═▷ Prot . Aux OFF•
• ╚═▷ Prot . SCmd ON•
•
╚═▷ ExP[1] . Trigger Signal
•
• ╚═▷ ExP[2] . Trigger Signal•
Description
“-”
Prot . DI 1 Signal: Digital Input
Prot . DI 2 Signal: Digital Input
Def. Autom. Reset
The automatic reset will reset all latched LEDs, all DiggiMEC Flag Indicators, and a fault/trip
info that might be visible on the DiggiMEC display. This is done depending on this setting,
when a new protection pickup occurs or after a particular time has elapsed.
Selection list referenced by the following parameters:
• ╚═▷ Prot . Def. Autom. Reset•
Def. Autom. Reset Description
OFF (=No Autom. Reset) OFF (=No Autom. Reset)
With a New Pickup Automatic Reset when a new protection trip occurs
New Pickup or After 1 h Automatic Reset when a new protection trip occurs or after 1 hour
New Pickup or After 2 h Automatic Reset when a new protection trip occurs or after 2 hours
New Pickup or After 4 h Automatic Reset when a new protection trip occurs or after 4 hours
New Pickup or After 8 h Automatic Reset when a new protection trip occurs or after 8 hours
New Pickup or After 12 h Automatic Reset when a new protection trip occurs or after 12 hours
New Pickup or After 24 h Automatic Reset when a new protection trip occurs or after 24 hours
134 WIC1 WIC1-2.0-EN-REF
13 Selection Lists
