Seg WI Series Reference Manual

9.10 I>>> – Phase Overcurrent Stage
9.10.1
I>>>: Device Planning Parameters
I>>> . Mode [Device planning / Projected Elements]
“-”
Only available if:
• Prot . Settings valid = Software•
“-”, use
╚═▷ Device planning
P.1
Phase Overcurrent Stage, general operation mode
I>>> . De󰈛nition [Device planning / De󰊟nition]
Trip
Only available if:
• Prot . Settings valid = Software•
Trip, Alarm
╚═▷ De󰊟nition
P.1
Phase Overcurrent Stage: If set to “Alarm”: The function operates as a supervision function, i.e. a fault generates
neither alarm nor trip, but an »Alarm« signal gets issued instead. If set to “Trip”: The function operates as a
protection function, i.e. trips the breaker in case of a fault.
9.10.2
I>>>: Settings
I>>> . Function [Protection Para / I>>>]
Active Inactive, Active
╚═▷ Mode
P.1
Permanent activation or deactivation of module/stage.
64 WIC1 WIC1-2.0-EN-REF
9 Protection Parameter
9.10 I>>> – Phase Overcurrent Stage
