Lateral Terminals
Current measuring inputs
DiggiMEC
WIC1_Z09
X0 / X1, X2, X3
X5
Ethernet
X7
PE
Inputs
Outputs
X4
: RS485
X6
Fig. 6: Main groups of connectors at the side of the WIC1.
The WIC1 has all connectors located at one side of the housing, so that it is convenient to
connect the required cables.
55WIC1WIC1-1.0-EN-MAN
3 Hardware
3.1 Overview of Elements and Connectors
