ASSEMBLY AND INSTALLATION
25
6
If grounding has been established with the ground wire inside the power cord,
do not perform grounding with the AC unit ground terminal. Conversely, if the AC
unit ground terminal has been used for grounding, do not establish ground with
the ground wire in the power cord. Otherwise there could be faulty or erroneous
operations
1
Conrm that the main switch is at OFF
2
Fully insert the power cord connector on the side opposite the power plug into the AC unit inlet
Main switch OFF
INLET
FUSE
MAIN SWITCH
4
The power cord is laid out indoors. Protect the
power cord by attaching wire cover to it.
If ground will be established with a ground wire
made available separately, lay out the ground
wire indoors and have it protected
3
Fully insert the power cord plug into the outlet
To Next Page
