Sega bop it ARCADE User Manual

44
EXPLANATION OF TEST AND DATA DISPLAY
9
o Bookkeeping Screen 16
 Z4 REACH = The number of games that ended in Zone 4
 Z5 REACH = The number of games that ended in Zone 5
o Bookkeeping Screen 17
 Z6 REACH = The number of games that ended in Zone 6
 Z7 REACH = The number of games that ended in Zone 7
o Bookkeeping Screen 18
 Z8 REACH = The number of games that ended in Zone 8
 Z9 REACH = The number of games that ended in Zone 9
o Bookkeeping Screen 19
 Z10 REACH = The number of games that ended in Zone 10
o Bookkeeping Screen 20
 The number of time LIFE 1 & 2 have been used.
o Clear Meters
 Pressing TEST will prompt the Operator “Are You Sure”?
 Pressing TEST a second time will clear all bookkeeping meters to ZERO
 A confirmation message “ALL CLEARED” will be shown and a confirmation audio SFX
will be played
o Clear IOU & Service meters
• The above procedure is repeated for clearing the IOU & Service Meters
3. SYSTEM INFO
• General
o System Info contains general information and version numbers for system hardware and
software
o Pressing the SERVICE button will cycle through the available test functions.
o Pressing the TEST button will activate the selected Test Function
• Operation
o Game Name and Version Info
o Hardware and Serial Number Info
BOP IT ARCADE
Version 1.00S
CLEAR METERS
1 LIFE = X
2 LIFE = X
