EXPLANATION OF TEST AND DATA DISPLAY
45
9
4. LIGHTING TEST
General
o Lamp Test contains test functions for the lighting elements of the Cabinet
o Pressing the TEST button will activate the selected Test Function
Operation
o All Lamps Test
When OFF is displayed, all lamps in the cabinet will be OFF
Pressing TEST button will toggle the Lamp state from OFF to ON.
When ON is displayed, all lamps in the cabinet will be ON
This includes any lighting driven from CAN bus devices.
o Direct LED Outputs
Pressing the TEST button will advance to lamp 000, pressing TEST again will advance
to 001 and so on.
The colour of the Lamp being lit is displayed next to the Lamp ID
o Lighting Test
The current Multiplex output being tested is displayed
Pressing TEST will advance to the next multiplex output to be tested
The Test will run from ROW 01 to ROW 16, and then test COL 01 to COL 16
Pressing the SERVICE button will terminate the test.
5. DISPLAY TEST
General.
o Display Test contains test functions for the Cabinet 7 segment LED and LED Matrix Displays
o Pressing the TEST button will activate the selected Test Function
o Pressing the SERVICE button will move to the next available test function. Any current test
operation will be aborted.
Operation
All Lamps
off
LIGHTING TEST
LED STEP DIRECT
LED STEP MUX
MUX: 015 RED
BOOTLOADER: v1.0
Serial: 0123ABCD
