GAME BOARD
15
15-6 DIP SWITCH SETTINGS
Bop It! - DIL Switch Settings
SW STATE
FUNCTION
ON *HQ AUDIO PCB - MUST BE ON
OFF SD Audio
ON SHOW MODE - Ticket Payout OFF
OFF SITE MODE - Ticket Payout ON
ON CEC MODE ON
OFF CEC MODE OFF
ON
NOT USED (N/U)
OFF N/U
ON * WATCHDOG - MUST BE ON
OFF
ON
N/U
OFF
N/U
6
The settings below are Standard Factory default settings.
1
2
3
4
5
1
2
3
4
5
6
OFF
ON
