EXPLANATION OF TEST AND DATA DISPLAY
9
o Ticket Output
• If TEST is pressed, the Selected Ticket Vend will dispense until the opto signal is
received.
o Meter Test
• If TEST is pressed, the Selected Meter Output will be pulsed one (1) unit to validate
the Meter Output driver.
• If Multiple Meter Outputs exist, pressing the SERVICE button will select the next
Meter Output.
• The Coin Meter is not accessed via this test.
8. AUX CAN
• General. NOT USED
9. COMS
• Serial Coms. NOT USED
10. AUDIO SETTINGS
• General
METER OUTPUTS
TEST GAME METER
TICKET OUTPUTS
TICKET VEND
TICKET OUTPUTS
VEND OK
