Sega bop it ARCADE User Manual

CONTROLLER UNIT
55
10
10-1-4 - Removing the "Spin-It" Control Unit
1
With the power OFF. Unlock and remove the Door Back Lower
3
Remove the (4) M6 xings highlighted and remove the assembly (be sure to support the controller from
underneath when removing these xings)
2
Disconnect the related harnessing. Remove the (1) xing from the Cabinet front
