58
COIN HANDLING
11
Remove and clean smears by using a soft cloth dipped in water or diluted chemical detergent and then
squeezed dry.
Remove the CRADLE. When removing the
retaining ring (E ring) be very careful so as not to
bend the rotary shaft.
Remove stain from the rotary shaft and shaft
receiving portions by wiping o with a soft cloth.
etc.
After wiping o as per previous step, further apply a dry cloth to completely dry the Coin Selector.
CLEANINGTHECOINSELECTOR(MECHANICAL)
Once every month, when performing the Coin SW Test, simultaneously check the following:
Does the Coin Meter count satisfactorily?
Does the coin drop into the cashbox correctly?
Is the coin rejected when inserted while keeping the REJECT Button pressed down?
Coin Insertion Test
CRADLE
Insert a coin while keeping
the REJECT Button
pressed down and check if
it is rejected.
1
2
3
4
To Next Page
