Sega bop it ARCADE User Manual

GAME BOARD
83
15
LOCATION TYPE
J11 4W JST VH
11
SD CARD READER FAT16
LOCATION TYPE
J12 26W JST RA TYPE
12
DIGITAL INPUTS MUX0-15
LOCATION TYPE
J14 26W JST RA TYPE
LOCATION TYPE
J15 40W JST RA TYPE
LOCATION TYPE
J13 5W SIL HDR
14
13
DIRECT DIGITAL INPUTS
LED MUX ARRAY
BOOT LOADER - DEV PURPOSES ONLY
15
27
28
29
30
31
32
33
40
39
38
37
36
35
34
LOCATION TYPE
J16 26W JST RA TYPE
ANALOGUE INPUTS
16
LOCATION TYPE
J17 6W JST PH K S
17
RGB
LOCATION TYPE
J18 6W JST VH - VNR-6N
18
MOTOR PORT C
LOCATION TYPE
J19 16W JST RA TYPE
7-SegmentLEDDisplay
19
