GAME BOARD
85
15
30
CAN PORT
LOCATION TYPE
J30 3W JST NH
29
COMMS RS232
LOCATION TYPE
J29 5W JST NH
CAN PORT
LOCATION TYPE
J31 9W D Type Female
1
2
3
4
5
6
7
8
9
31
32
AUDIO BRIDGE
LOCATION TYPE
J32 3W JST NH
33
AUDIO
LOCATION TYPE
J33 4W JST NH
34
DIP SWITCH
LOCATION TYPE
J34 USB2 PORT
