Pneumatic connector 'IN'
input for the connection of the branch of the gas sampling probe with the condensation separating and
anti-dust filter assembly.
M
'P-' Pneumatic connector
Pressure negative input (P-): used for measuring draft according to the standard UNI10845; it connects to
the second hose (with the larger pneumatic connector) of the sample probe for simultaneous measurement
of draft and combustion analysis.
L
'P+' pneumatic connector
Positive input (P+): used for measuring the pressure in general as well as for the leakage test.
N
Inputs ‘P+’ and ‘P-’ are respectively the positive and negative inputs of the internal
differential pressure sensor, piezoresistive, temperature compensated; therefore these can
be simultaneously used to measure the differential pressure.
'T2' Connector
Used to connect the Tc-K plug of the combustion air temperature probe.
F
'T1' Connector
Used to connect the Tc-K male connector of the gas temperature probe.
G
Gas outlet
H
'AUX' Connector
Input for optional external probes.
I
Cover to access battery compartment.
O
Cover to access cell compartment.
P
Magnets.
Q
Instrument data label.
