40
K600000000SE 030804 011018
10.2.8 Configuration→Analysis→Air temperature
→
Configuration
Air temperature
15/01/14
10:00
Probe T
°C
25.0
Air T
°C
-----
CONTEXT KEY FUNCTION
Accesses the Editing mode of the parameter ‘Air T’: it is possible to enter
the desired value of the combustion air temperature that will be used in the
combustion analysis.
It saves the value, acquired or entered in the parameter ‘Air T’.
Acquires the temperature value detected from the sampling probe. That
value is reported in the parameter ‘Air T’.
Confirms the operation.
KEY FUNCTION
Activate the context keys shown on the display.
When in modify mode, sets the desired value.
Activates the context key located in the left side of the display.
Returns to the previous screen without saving the changes made.
OK
