65
K600000000SE 030804 011018
→
When the stabilization time is over, select the 'Calibration' row and activate the function ' ' to store the
new calibration.
OK
Messages in the 'Status' line:
saving: the instrument is saving the
performed calibration
error: the sensor has NOT been
recalibrated for any of the following
reasons:
- The calibration gas cannot
properly reach the instrument.
- Concentration for the calibration
gas has not been set in the
relevant line ‘Applied gas’.
- The user didn’t allow for the
stabilization time to properly
elapse.
- The sensor could be damaged or
exhausted and must therefore be
replaced.
On site calibration
Sensor O
2
15/01/14
10:00
Is
uA
5.72
Measured gas
%
0.7
Applied gas
%
0
Elapsed time
00:03:00
Status
non attiva
Calibrate
OK
On site calibration
Sensor O
2
15/01/14
10:00
Is
uA
5.72
Measured gas
%
0
Applied gas
%
0
Elapsed time
00:03:00
Status
attiva
Calibrate
OK
OK
WARNING
At any time the user can restore the factory calibration in the instrument by setting
the 'Status' line on 'not active'.
