Selec ATSEL FD300 User Manual

25
24
Digital setting
of torque
upper limit
in speed
control mode
0.0%~200.0% 150%
Excitation
adjustment
proportional
gain
0~60000 2000
Excitation
regulation
integral gain
0〜60000 1300
Torque
adjustment
proportional
gain
0〜60000 2000
Torque
adjustment
integral gain
0〜60000 1300
Speed loop
integral
separation
0 : Invalid
1 : Valid
0
Maximum
output
voltage
coefficient
100%~110% 105%
Weak
magnetic
zone
maximum
torque factor
50%~200% 100%
Function
Code
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
P2-10
P2-13
P2-14
P2-15
○
○
○
○
P2-16
○
P2-17
○
P2-20
●
P2-21
○
P3: V/F Control parameters
Function
Code
Parameter
Name
Setting Range
Default
Prope-
rty
Modbus
Address
P3-00
V/F Curve
setting
0
Torque boost
0.0%(Auto) 0.1%〜30.0%
Cut-off
frequency of
torque boost
0.00Hz〜Maximum frequency
50.00Hz
Multi-point
V/F frequency 1
0.00Hz〜P3-05 0.00Hz
Multi-point
V/F voltage 1
0.0%〜100.0% 0.0%
Multi-point V/F
frequency 2
P3-03〜P3-07 0.00Hz
0.0%〜100.0% 0.0%
P3-05〜Motor rated frequency
(P1-04）
0.00Hz
0.0%〜100.0% 0.0%
V/F Slip
compensation
gain
0.0%〜200.0% 0.0%
0〜200 64
V/F oscillation
suppression
gain
0〜100
Oscillation
suppression
mode selection
0~4 3
Voltage source
for V/F
separation
0
Voltage digital
setting for V/F
separation
0 V~rated motor voltage
0V
Voltage rise
time of V/F
separation
0.0s~1000.0s 0.0s
0 : Linear V/F 1 : V/F
2 : Square V/F
3 : 1.2-power V/F
4 : 1.4-power V/F
6 : 1.6-power
8 : 1.8-power V/F
9 : Reserved
10 : V/F complete separation
11 : V/F half separation
●
P3-01
Fun-
ction
Code
Parameter
Name
Setting range
Default
Prope-
rty
Modbus
Address
Model
dependent
P3-02
●
P3-03
●
P3-04
●
P3-05
●
Multi-point V/F
voltage 2
P3-06
●
Multi-point V/F
frequency 3
P3-07
●
Multi-point V/F
voltage 3
P3-08
●
P3-09
V/F over-
excitation gain
P3-10
P3-11
Model
dependent
P3-12
P3-13
0 : Digital setting(P3-14) 1 : AI1
2 : AI2 3 : AI3
4 : Pulse setting(HDI)
5 : Multi-function
6 : Simple PLC 7 : PID
8 : Communication setting
Note:100.0% corresponds to the
rated motor voltage
P3-14
P3-15
○
○
○
○
●
○
○
○
User Manual
Chapter 5
User Manual
Chapter 5
61963
61966
61967
61968
61969
61970
61973
61974
62209
62210
62211
62212
62213
62214
62215
62216
62217
62218
62219
62220
62221
62222
62223
62224
