Setting of the end positions
4. Setting of the end positions
4.1. Delivery status
In the SELVE delivery status no end positions are programmed into the motor! Safety
functions are deactivated at delivery and will only become active after both end posi-
tions are set.
In delivery status the SE Plus is in semi-automatic programming mode.
4.2. Setup functions
The end positions setting of a SELVE motor is possible via:
• the setting switch for SELVE motors (item no. 290103) or with
• any standard switch (only in semi-automatic mode) or with
4.3. Mechanic requirements
The operation of the SE Plus as roller shutter drive is possible by using safety springs
or blocking springs. When using the SE Plus as awning motor the awning fabric will
often be connected directly with the fabric shaft.
Caution:
There is no automatic setting of the lower end limit when using the SE Plus. The lower
end limit has always to be run-up to or also set.
Caution:
When setting in semi-automatic and manual setting mode, a fixed upper end limit has
to exist if this end limit has to be recognized from the drive automatically.
4.4. Selection table for settings
Setup-mode/end positions in operation Setting switch
Semi-automatic setup-mode
bottom position, top stop/release*
4.5.1. (page 28)
Manual setup-mode
bottom position, top stop/release*
4.5.2. (page 29)
Manual setup-mode
bottom position, top position
4.5.3. (page 30)
* Both setting procedures are leading to the same result:
bottom position: point, top position: limit stop/relief
