Setting of the end positions with setting switch
4.5.3. Manual setup-mode, deletion and manual setting of the end positions
¨ in operation bottom position, top position
When the movement is interrupted once, the system is in manual setup-mode.
In manual setup-mode, the lower end position must be set and stored first. Afterwards,
the upper end position can be set and stored.
Operation Drive
E
6 s
Press the E button of the setting switch for 6 seconds.
The motor will switch to manual setting mode. Both limit
positions already set will be deleted.
E
Move the motor to the lower end position with the UP or
DOWN button.
E
3 s
Press the E button for 3 seconds.
The correct rotation direction assignment will be carried out
at the end of the end position setting.
E
Move the motor to the designated upper end position.
E
3 s
Press the E button for 3 seconds.
The end positions are now set and the rotation direction
assignment is correct. Perform a test run.
