Technical data
6. Technical data
Series
Torque
Nm
Rotation speed
Rpm
Power Input
A
Output
W
1/6 6 15 0.5 115
1/10 10 15 0.5 115
2/6 6 28 0.45 105
2/7 7 17 0.41 95
2/9 9 28 0.66 152
2/10 10 17 0.45 105
2/12 12 28 0.75 172
2/15 15 17 0.66 152
2/18 18 28 0.95 220
2/20 20 17 0.75 172
2/30 30 17 0.95 220
2/40 40 17 1.5 345
2/50 50 12 1.5 345
3/50 50 17 1.4 315
3/60 60 12 1.1 245
3/70 70 17 1.9 435
3/80 80 12 1.4 322
3/120 120 11 1.9 435
Series 2 motors have a plug-in connection cable. Series 1 and series 3 motors have a
2.5 m mains cable as standard which is permanently installed and cannot be
replaced.
The relevant cable lengths and qualities for series 2 can be selected in the catalogue.
Connection cables must be ordered separately.
Information about connections using special connectors must be requested.
Information for all motor types:
Nominal voltage: 230 V AC/50 Hz
Safety class: IP 44
Subject to change without prior notice!
