40
Figure 51. Tightening a bed knife bolt
8. Using a 1/2” wrench, attach front and rear deflectors as shown with eight 5/16”-18 x 1-1/4" hex bolts
and 5/16” lock washers. See also Figure 42, page 35, for the bolt locations.
Figure 52. Front deflector
Figure 53. Rear deflector
9. Do a final check of bolt torques, assembly bolt tightness, and knife gap.
