Figure 65. Left side of the SSD2-HS disintegrator cabinet
Figure 66. SSD2-HS disintegrator and vacuum
fan system
Figure 67. Vacuum fan system
Control
power
button
Hour Meter
Flex vacuum
hose inlet
Filter
door
Drum foot pedal bar
Hose adapter
Drum
Vacuum fan system
control panel
Vacuum flex
hose
