Figure 68. Cutting chamber front, guard panel removed
Figure 69. Left rear, SSD2-HS disintegrator cabinet, cover removed
Drawer handle
Stage 1 cutting
chamber
Belt guard
Drawer securing
bolt
Bed knife adjustment bolts
Drawer
securing bolt
Hopper
Hopper seal
Stage 2
chamber
Stage 1
chamber
Stage 2
motor
Hopper
Hopper seal
Stage 2 cutting
chamber
