SEM SSD2-HS - Page 52

508.366.1488 | www.semshred.com
52
Figure 70. Rear of SSD2-HS disintegrator cabinet, covers removed
Figure 71. SSD2-HS disintegrator electrical panel
Secondary fuse
Primary fuses
Current
transformer
Power cord
Contactors
24V DC
power supply
Overloads
PLC
Power cord
Stage 2
chamber
Stage 1
chamber
Stage 2
motor
Belt guard
Electrical panel
