ADN Digital Conference System |19

Overview of the components

NT 12-50C power supply

The power supply can charge one ADN-W BA battery pack or can optionally power

the ADN-W AM antenna module.

Mains cable with mains plug

(with EU, UK or US mains plug,

depending on version)

Hollow jack plug

Euro 8 socket for mains cable

NT 12-50C
