Sennheiser ADN CU1 - ADN D1 Delegate Unit

Overview of the components
12 | ADN Digital Conference System
ADN D1 delegate unit
Sound inlet basket with glued
windshield
Signal light ring
Headphone socket
Headphone volume control for
headphone socket
Microphone key
Microphone LED
Loudspeaker
IN socket
OUT socket
Type plate
(see bottom)
:
