Sennheiser ADN CU1 - Combining Wired and Wireless Conference Units (Hybrid Operation)

ADN Digital Conference System |33
Structuring and controlling the conference system
Combining wired and wireless conference units
(hybrid operation)
ADN C1 and ADN D1 wired conference units and ADN-W C1 and ADN-W D1 wireless
conference units can be combined arbitrarily (hybrid operation) as long as
you ensure correct set-up and cabling and comply with the specifications (see
page 56).
ADN-W AM
ADN PS
(max. 15)
ADN CU1
max. 400
ADN D1/ADN-W D1/ADN C1/ADN-W C1
max. 150
ADN-W D1/ADN-W C1
ADN CU1
ESC
ADN PS
1
50
ADN PS
ADN-W D1/
ADN-W C1
ADN D1/
ADN C1
ADN D1/
ADN C1
