Putting the conference system into operation
72 | ADN Digital Conference System
To protect the antenna module from accidental dropping:
왘 Guide a safety wire through the hole for safe
ty wire and attach the safety
wire e.g. to a separate hook.
Mounting the antenna module to the ceiling
왘 F
or ceiling mounting, use the optional GZG1029 swivel joint and GZP 10
mounting plate.
To protect the antenna module from accidental dropping:
왘 Guide a safety wire through the hole for safe
ty wire and attach the safety
wire e.g. to a separate hook.
Mounting the antenna module to a stand
왘 Orient the legs of the stand.
왘 Select a suitable mounting threa
d
(supplied) for your stand:
– without thread insert: 5/8" thread
– thread insert: 3/8" thread
