Instruction Manual Multiscan 8+
ENGLISH
1.3 Accessories ordering codes
Table 3: Multiscan 8+ accessories codes
CODE
DESCRIPTION
STG/IN8S
High safety 8-input remote module with improved performance for
MULTISCAN++S1 control panel.
STG/16REL
16-relay card to be connected to MULTISCAN 8+ and STPL4/ESP to
provide additional 16 relay outputs
STG/OUT16S
High safety 16-output remote module (Open collector type) with
improved performance.
STG/8REL
Plug and play relay board to be connected to STG/OUT16 to provide 8
relay outputs
STG/MTSS1-
CONF
Windows PC software for MULTISCAN++S1 control panel programming.
Running under Windows XP, VISTA, WIN7, 8, 8.1, 10.
The configuration software is supplied along with the control panel
1.4 Technical specifications
Table 4: Multiscan 8+ technical specifications
Technical specifications
Housing:
IP 42 plastic box, 420x380x160 mm
Inputs:
Max. 16 detectors
Outputs:
6 relays in the central unit
16 through the STG/16REL card to be connected inside
the central unit
16 O/C or relay outputs via the STG/OUT16-S and
STG/8REL remote cards.
Serial ports:
1 x RS485
1 x RS232 (PC connection)
Power:
230 Vac
Absorption:
Max 10 VA
Display:
Liquid crystal display (LCD)
Optic indications:
Double row of 9 LEDS
