3 INSTALLATION
The chapter explains the procedures for the operation, powering on and maintenance of
the Multiscan 8+ central unit
The Multiscan 8+ central unit can only be programmed by means of a personal computer
with the appropriate software.
Fig. 3) Front panel of the central unit
3.1 Power ON
After ensuring correct installation of the system, the Multiscan 8+ central unit can be
switched on. When first switched on, after the “Warm Up” time (3 minutes by default),
the display will be blank as the central unit needs to be programmed.
Fig. 3.1 a) Warm Up screen
Programming can only take place via a personal computer with a special program. See
chapter 4.
For a system that is already configured, the screen under normal conditions will be the
display of programmed channels (gas detectors). Maximum 3 channels per screen.
