Instruction Manual Multiscan 8+
ENGLISH
2.1.5 Setting of the communication bus, RS232 PC serial and central unit
language
The series of SD2 dip-switches are used to set the following:
• Baud Rate (communication speed) and RS485 bus protocol with field devices
(detectors and IN/OUT modules).
• Baud Rate (speed) of communication of the RS232 serial port to the personal
computer
The series of SD3 dip switches is used to set the language of text on the display of the
central unit.
Table 5: Dip-switch 1: Baudrate bus RS485
Position
Bus communication speed
Detector and module compatibility
ON
115200
Smart “S” gas detectors; ST.G/IN8-S
and ST.G/OUT16-S modules
OFF
9600
Smart “3G” gas detectors; ST.G/IN8-S
and ST.G/OUT16-S modules
Table 6: Dip-switch 2 and 3: Communication protocol
Sw 2
Sw 3
Protocol
Detector and module compatibility
Notes
ON
ON
Galileo
Smart “S” gas detectors; ST.G/IN8-S
and ST.G/OUT16-S modules
Baud Rate 115200
OFF
ON
Setting not used
ON
OFF
Modbus
Smart "G" gas detectors; STG/IN8-S
and STG/OUT16-S modules
Baud rate 9600 (if
they are not
connected to the
Smart "G" bus
detectors, 115200
Bps can be set
(switch 1)
OFF
OFF
Setting not used
Table 7: Dip-switch 4 and 5: RS232/USB baudrate
Sw 4
Sw 5
Baud Rate
ON
ON
9600 Bit/sec.
OFF
ON
19200 Bit/sec.
