Appendix C Parts List Io
SENSOR
106
SMT-200 Operations and Technical Manual 2.00/R1
Capacitors
Reference Part
Part Number
C23,C32,C33,C34,C35,C36,C37,
C38,C40,C41,C42,C43,C44,C45,C46
,C51
100nF SMT-200 T 0038
C53 100nF SMT-200 T 0039
C15,C17, C30, C31 100pF 1000V CER SMT-200 T 0040
C21 100uF 63V Vert. (high quality) SMT-200 T 0041
C12,C22 10n SMT-200 T 0042
C27,C39 10uF 25V Tant. SMT-200 T 0043
C6, C52 1uF SMT-200 T 0044
C10 1uF 35V Tant. SMT-200 T 0045
C3,C8,C9,C13,C14,C18,C19,C47,
C48,C49,C50
220nF SMT-200 T 0046
C28 220uF 35V Vert. SMT-200 T 0047
C26 270pF SMT-200 T 0048
C1,C2 2u2F 25V Tant. SMT-200 T 0049
C5 330nF SMT-200 T 0050
C20 330uF 16V Vert. SMT-200 T 0051
C24,C25 33uF 25V Tant. SMT-200 T 0052
C29 470p SMT-200 T 0053
C4,C7,C16 47nF SMT-200 T 0054
C11 56nF SMT-200 T 0055
Semiconductors
Reference Part
Part Number
D3,D4,D5,D6,D7,D8,D12,D13 1N4006 SMT-200 T 0056
D1,D2,D10 1N4148 SMT-200 T 0057
U12 27C1024 PLCC44 SMT-200 T 0058
U9 74C922 SMT-200 T 0059
U15 74HCT153 SMT-200 T 0060
U10 74HCT4040 SMT-200 T 0061
U5 82C55 PLCC44 SMT-200 T 0062
U7 AD7111 SMT-200 T 0063
U6 ADS7807P SMT-200 T 0064
A8200112 PCB assm II PC/104 Mod Ampro CoreModule/PC 2 MB SMT-200 T 0065
D11 B2T03C16 SMT-200 T 0066
Q4 BC517 SMT-200 T 0067
U19
Brandner SH3W2-23 or Traco TEF2022
SMT-200 T 0068
Q1,Q2,Q3,Q5,Q6 BS170 SMT-200 T 0069
Q7 BS250 SMT-200 T 0070
U22 CD4093 SMT-200 T 0071
U3 CD74HCT00 SMT-200 T 0072
U1 CD74HCT139 SMT-200 T 0073
U2 CD74HCT245 SMT-200 T 0074
U4,U14 CD74HCT30 SMT-200 T 0075
U11 DAC707 SMT-200 T 0076
U16 DG408DJ / ADG408BN SMT-200 T 0077
U18 DG409DJ / ADG409BN SMT-200 T 0078
