Appendix E Quick Reference
SMT-200 Operations and Technical Manual 2.00/R1
131
E.1 Quick Reference
Function Action LCD Display Keys
1 2 3 4 5
About About
6 (or 5)
Audible warnings ON/off Beeps
2 6 4
Autonumbering ON/off Autonumber ON/off
2 3 1
Configuration - Read from disk Read Config
4 6
Configuration - Write to disk Save Config
4 7
Continue test on a reject Toggle Cont on reject
2 3 4
Continuous Impedance test bar graph range Value Bar-range
2 5 5
Continuous mode test interval Value Interval
2 3 8
Continuous test Maximum number of tests Value Max_Test
2 5 4
Continuous test mode ON/off Continuous
2 3 7
Data file - Dump to Com. port Dump data file
4 3
Data file - Erase ALL data from memory Erase ALL data
4 5
Data file - List contents List data file
4 4
Data file - Storage status Storage status
4 2
Date & Time Date & Time
2 8
Date & Time - Display & Modify Value Date & Time
2 8
Diagnostics Diagnostics
2 9
Diagnostics - Analogue circuits test Analogue
2 9 7 1
Diagnostics - Attenuator settings Attenuator
2 9 6 6 2
Diagnostics - Audible warning device test Sound
2 9 5 5
Diagnostics - Backlight on/off test Backlight
2 9 5 3
Diagnostics - Battery voltage and Lo switch point test Battery
2 9 6 4
Diagnostics - Display - selects display tests Display
2 9 5
Diagnostics - Display contrast range test Contrast
2 9 5 4
Diagnostics - Display pixel test Pixels
2 9 5 2
Diagnostics - Gain range & offset test AC AC Gain range
2 9 7 3
Diagnostics - Gain range & offset test DC DC Gain range
2 9 7 4
Diagnostics - Hardware tests Hardware
2 9 6
Diagnostics - Keypad button test Keys
2 9 5 1
Diagnostics - Leakage test Leakage
2 9 7 5
Diagnostics - Leakage test - Calibrate Value Iopa
2 9 1
Diagnostics - Noise test Noise
2 9 7 2
Diagnostics - Post Mortem (shows last shutdown status) Post Mortem
2 9 3
Diagnostics - Power up analogue circuit DC/DC
2 9 6 6 1
Diagnostics - Ref./Geo relay contact test Relay
2 9 6 5
Diagnostics - Resets all tester setting to default values Reset All
2 9 4
Diagnostics - Serial port (RS232) communication test Serial port
2 9 6 1
Diagnostics - Simulation - no real test ON/off Simulation
2 9 2
Diagnostics - Sine wave frequency settings Freq.
2 9 6 6 3
Diagnostics - Sine wave generator test Sine wave
2 9 6 6
Diagnostics - Temperature sensor test external Extemp
2 9 6 3
Diagnostics - Temperature sensor test internal InTemp
2 9 6 2
Diagnostics - Tests Tests
2 9 7
Display - Backlight ON/off Backlight
2 6 1
Display - Backlight on time (power saving) Enter Value B-Light
2 7 2
Display - Contrast decrease - LCD Contrast
2 6 3
Display - Contrast increase + LCD Contrast
2 6 2
