SMT-200 Operations and Technical Manual 2.00/R1
Function Action LCD Display Keys
1 2 3 4 5
Display - On time (power saving) Enter Value Display
2 7 3
Display menu Display menu
2 6
Erase ALL data from memory Erase ALL data
4 5
File menu File menu
4
Full test mode (display all results) Toggle Full test
2 3 3
Geophone file - Copy geophone type Copy
2 2 3
Geophone file - Delete geophone type Delete
2 2 4
Geophone file - Edit geophone type Enter Value Edit
2 2 2
Geophone file - Select geophone type Select
2 2 1
Geophone menu Geophone menu
2 2
Go /No Go test (display as only good or bad) Toggle Go /No Go Test
2 3 3
Imperial units Toggle Imperial units
2 6 6
Interval between tests in Continuous mode Enter Value Interval
2 3 8
Keypad Beeps ON/off Key Beeps
2 6 5
Lead-in length Enter Value Lead-in
2 1 6
Leakage test reject limit Enter Value Leak
2 5 3
Limits menu Limits menu
2 5
List contents of the data file List data file
4 4
Log-off time Enter Value Log-off
2 7 5
Low_Drive test excitation level Enter Value Low_Drive
2 5 1
Metric units Toggle Metric units
2 6 6
Noise test reject limit Enter Value Noise
2 5 2
Operating menu Operating menu
2 3
Polarity test tap sensitivity Enter Value Pol_Sens
2 5 6
Power menu Power menu
2 7
Power savings enable ON/off Saving
2 7 1
Power SMT-200 Tester On Power Tester On
Enter / Start
Redisplay last test results Redisplay last
4 1
Repeat geophone Test Repeat Test
+/-
Return to the main Menu Back to main
. or 0
Save reject tests too Save rej's
2 3 2
Serial Number About...
6 (or 5)
Setup menu Setup menu
2
Shunt Resistor - Enable Yes/No Use shunt?
2 1 7
Shunt resistor value Enter Value Shunt
2 1 8
Shut-down time (power saving) Enter Value Shut-down
2 7 4
Skip rest of test on a reject Toggle Skip on reject
2 3 4
Software Version About...
6 (or 5)
Start next geophone test Enter Start next Test
1 Enter/Start
Storage status Storage status
4 2
String - Elements in parallel Enter Value Parallel
2 1 3
String - Elements in series Enter Value Series
2 1 2
String - Geophone interval Enter Value Interval
2 1 5
String - Shunt resistor value Enter Value Shunt
2 1 8
String - Specific cable resistance Enter Value Rcab
2 1 4
String - Test number Enter Value No.
2 1 1
String configuration menu String menu
2 1
Tag - Display tag list & test/string number Tag list
5 2
Tag - Read tag & allocate/display test/string number Read tags
5 1
