SENSOR
Appendix E Quick Reference
SMT-200 Operations and Technical Manual 2.00/R1
133
Function Action LCD Display Keys
1 2 3 4 5
Tag menu Tag menu
5
Temperature - Enable Smartec ON/off Smartec
3 3
Temperature - Measure Smartec Temp. Smartec Temp.
3 4
Temperature - Measure using Reference SM-4 Ref. Geo Temp.
3 2
Temperature - of string Temp.
3 1
Temperature Correction on Data Toggle T-Corr on Data
2 3 6
Temperature Correction on Specification Toggle T-Corr on Spec
2 3 6
Temperature menu Temp. menu
3
Test - Continuous Impedance bar graph range Enter Value Bar_range
2 5 5
Test - Distortion & Impedance ON/off Dist. Imp
2 4 7
Test - Frequency, Damping & Sensitivity ON/off Fn, Bo, Go
2 4 6
Test - Leakage ON/off Leakage
2 4 4
Test - Leakage reject limit Enter Value Leak
2 5 3
Test - Low Drive ON/off Low Drive
2 4 1
Test - Low_Drive excitation level Enter Value Low_Drive
2 5 1
Test - Maximum number of test in Cont. mode Enter Value Max_Test
2 5 4
Test - Noise ON/off Noise
2 4 3
Test - Noise reject limit Enter Value Noise
2 5 2
Test - Polarity ON/off Polarity On/off
2 4 2
Test - Polarity First Toggle Polarity test First
2 4 9
Test - Polarity Last Toggle Polarity test Last
2 4 9
Test - Polarity tap sensitivity Enter Value Pol_Sens
2 5 6
Test - Resistance ON/off Resistance
2 4 5
Test a geophone (string) Do a test...
1
Test Continuous Impedance ON/off Cont. Imp
2 4 8
Test number Enter Value No.
2 1 1
Test with a Constant Excursion Toggle @ Constant Exc.
2 3 5
Test with a Constant Velocity Toggle @ Constant Vel.
2 3 5
Tests Sequence Tests Sequence
2 4
