SMT-200 Operations and Technical Manual 2.00/R1
In the following description the bold item represents the section and the remaining digits represent the
keystrokes required to access the selection.
Section
2.5.2.6.1 Backlight on/off
Keystrokes (In this case )
Redisplay Last
-----------------
No. 14
Temp 21.6
o
C
Pol 1
Leak 9.2 Mohm
Res 394 ohm
Freq 10.35 Hz
Damp 0.242
Sens 28.83 V/m/s
Dist 0.10 %
Imp 2393 ohm
-----------------
0 - File Menu
Storage status
----------------
Stored Records:
0
Estimated space:
3891 Records
----------------
0 - File Menu
File menu
----------------
1 Redisplay last
2 Storage status
3>Dump data file
4 List data file
5 Erase ALL data
6 Read Config
7 Save Config
Initialize
Start Terminal
then press 0
B
1 2 3
File Menu Structure
12 817 10.11 0.6
13 819 10.12 0.6
14 816 10.12 0.6
15 816 10.11 0.7
16 817 10.10 0.6
17 819 10.10 0.6
18 820 10.09 0.7
19 818 10.05 0.6
20 817 10.01 0.6
21 815 10.10 0.7
22 812 10.15 0.7
23 818 10.11 0.6
24 817 10.12 0.6
25 816 10.08 0.7
12 817 10.12 0.6
File menu
----------------
1 Redisplay last
2 Storage status
3 Dump data file
4 List data file
5>Erase ALL data
6 Read Config
7 Save Config
0 Back to Main
----------------
Enter to erase
0 - Cancel
File menu
----------------
1 Redisplay last
2 Storage status
3 Dump data file
4 List data file
5 Erase ALL data
6>Read Config
7 Save Config
0 Back to Main
----------------
Reading Config
File menu
----------------
1 Redisplay last
2 Storage status
3 Dump data file
4 List data file
5 Erase ALL data
6 Read Config
7>Save Config
0 Back to Main
----------------
Saving Config
4
5
6 7
2 6 1
