3. Low Oxygen Purity Below 70%)

Eclipse is: Beeping with a RED LED Flashing and the unit IS running.

A. What is the Eclipse liter flow?

B. What Flow Mode is set? (CONTINUOUS or PULSING)

C. If Continuous Flow – Is Eclipse is at least 3” away from anything that may block the vents

(i.e.: drapes, bedding, fabric or upholstery, and is the cabinet filter clean?

i. If “YES”, then your purity is low. Replace and repair the Eclipse. Contact your provider for further

instructions.

ii. If “NO” then relocate Eclipse for improved airflow and / or have your external cabinet filter cleaned.

D. If Pulsing Flow – Is the respiratory rate greater than the range on the chart below:

i. If “YES”, then switch to Continuous Mode until the respiratory rate is below the recommended rate,

then return to the pulse Mode

ii. If “NO” then purity is low. Exchange out the unit for evaluation and possible repair.

Pulse Flow Setting Bolus Size (+/- 15%) Min Breath Rate

AC Power 15 Amp 10 Amp

Supply and Switch Setting Switch Setting

Power Cartridge DC Power Supply DC Power Supply

Max Breath Max Breath Max Breath

Rate Rate Rate

1 16 6 40 40 40

2 32 6 40 40 40

3 48 6 40 40 40

4 64 6 39 39 31

5 80 6 31 31 25

6 96 6 26 26 20

Troubleshooting Guide
