2. Low Oxygen Purity (Between 85% & 70%)

My Eclipse has: a YELLOW LED flashing and the unit IS running. (NO Audible

Alarms)

A. What Flow Mode is Eclipse in CONTINUOUS or PULSING?

B. If Continuous Flow – Is Eclipse is at least 3” away from anything that may block the vents

(i.e.: drapes, bedding, fabric or upholstery, and is the cabinet filter clean?

i. If “YES”, then the purity is low. Replace and repair the Eclipse for low Purity. Contact your provider

for further instructions.

ii. If “NO” then relocate the Eclipse to improve airflow, and / or have your external cabinet filter cleaned.

C. If Pulsing Flow – Is the user respiratory rate greater than the range on the chart below:

i. If “YES”, then switch to continuous mode until the respiratory rate is below the recommended rate,

then the Eclipse can be returned the Pulse Mode

ii. If “NO” then the purity is low. Exchange out the unit for evaluation and possible repair.

Pulse Flow Setting Bolus Size (+/- 15%) Min Breath Rate

AC Power 15 Amp 10 Amp

Supply and Switch Setting Switch Setting

Power Cartridge DC Power Supply DC Power Supply

Max Breath Max Breath Max Breath

Rate Rate Rate

1 16 6 40 40 40

2 32 6 40 40 40

3 48 6 40 40 40

4 64 6 39 39 31

5 80 6 31 31 25

6 96 6 26 26 20
