LISST-200X User’s Manual LISST-200X Operation Details Page 77
G. LISST-200X Command Details
1. Display Commands
CONFIG
Display instrument hardware configuration
Syntax:
CONFIG
Description:
The current hardware configuration including Auxiliary I/O connector
configuration
Example:
input: CONFIG
output:
Serial Number: 2001
Firmware Version: 1100 (1.100)
VCC: 59371
Full Path Length: 2500 (25 mm)
Eff. Path Length: 2500 (25 mm)
BioBlock Installed: 0
Start Condition: Digital input (4)
Start Condition Data: 0
Stop Condition: Switch (3)
Stop Condition Data: 0
Measurements Per Average: 10
Sample Interval: 1 seconds
Burst Mode: 0
Samples Per Burst: 5
Burst Interval: 25 minutes
Transmit Raw Data: 0
Lifetime Sample Count: 529554
Lifetime Laser On Time: 1703980 seconds
Endcap Configuration: 0 (Analog & digital in)
Wiring of MCBH6MP connector:
1: Ground
2: Digital input 1
3: Digital input 2
4: +12V output
5: Analog input 1
6: Ground
