LISST-200X User’s Manual LISST-200X Operation Details Page 47
6. Using the Large External Battery Pack
The Large External Battery Pack is used to provide power to the LISST-200X for long term
deployments or extended profiling operations.
• The LISST-200X Large External Battery is shipped
with 16 Alkaline D batteries pre-installed and is ready
for use. The following steps describe how to open
the battery and replace the batteries. Skip to Step X to
connect the battery to the LISST-200X.
• The new alkaline batteries can be left in the battery
housing for storage. However, it is not recommended
that fully discharged batteries be left in the battery
housing during long term storage.
Battery ready to use
when shipped.
• To access and replace the batteries in the Large
Battery pack you will need remove the endcap with the
connectors and handle.
• Remove the four 6-32 X ¾ long socket head cap
screws from the connector endcap using the provided
7/64” ball driver. Remove the screws uniformly or hold
the cap down against the light spring force.
To Next Page
