LISST-200X User’s Manual LISST-200X Operation Details Page 38
4. Configuring Data Collection
The LISST-SOP software can be used to configure the Start and Stop Conditions, Fixed
Rate or Burst sampling and sample rates.
• Connect the instrument to the computer and establish
communication in the LISST-SOP200X program. (see Step-
by-Step Procedure: Establishing Communication with the
LISST-200X)
LISST-SOP open
and
communicating
with LISST-200X.
• Open the Sampling Programs window by choosing
Operating Modes from the LISST menu or by pressing the
button on the toolbar.
• To set the LISST-200X data logger clock to the computer
clock press the Set Clock button. Press the Refresh Status
button to refresh the display.
Instrument Status
Displayed.
Clock set
• To load a pre-saved LISST Operating Procedure file (LOP)
click the Load .LOP File button.
• After the file is selected, the appropriate settings are loaded
but not yet configure on the instrument. To apply these
settings to the instrument press the Apply or OK buttons.
• LISST Operating Procedure files can be saved by clicking
the Save Configuration as .LOP File button. The setting
must have first been sent to the instrument using the Apply
button.
• By selecting the Operating Mode Tab at the top of the main
To Next Page
