108
5. The padding command could be in any sequence.
Command Description
0x01 Motion Detection Padding, in video frame
The data length is 13.
Byte 1: Motion detection is enabled or not (main switch)
and whether it is in the effect schedule or not..
0x00 = 0 = Off
0x01 = 1 = On & not in effect schedule
0x11 = 17 = On & in effect schedule
Byte 2 ~ 5 Current motion indicator of the detected window
1 ~ 4
0 ~ 255
Byte 6 ~ 9 Current threshold of the detected window 1 ~ 4
0 ~ 255
Byte 10 ~ 13 Motion detect window 1 ~ 4 is enabled or not.
0 = Off
1 = On
0x11 Motion Detection Padding (extension), depends on models, in
video frame
Byte 1: The data length of the data, depends on the windows
number.
Byte 2: Motion detection is enabled or not (main switch)
and whether it is in the effect schedule or not.
0x00 = 0 = Off
0x01 = 1 = On & not in effect schedule
0x11 = 17 = On & in effect schedule
Block1~n: The Motion windows information block
8 bytes per block, the blocks numbers is the
windows number
Byte 1,2 in block: Current motion indicator of the
detected window, word type
0 ~ 65535, currently use only
0~255
Byte 3 in block: Motion detect window is
enabled or not
0 = Off
1 = On
Byte 4 in block: Current frequency of the
detected window,
