Event Trigger Screen
This screen is displayed when the Event Trigger option on the Event menu is clicked.
Figure 44: Event Trigger Screen
Data - Event Trigger Screen
Event Schedule
Schedule List
The Event Schedule shows all of the event types currently
configured in the Network Camera, along with various information
about their configuration, as listed below:
• Name - the descriptive event name set by the user.
• Effective Time Frame - shows when the event at a set time will
be triggered.
• Trigger by - shows what kind trigger activate the event.
• Action - shows what kind of the actions will be issued when the
event been triggered
New Schedule
Effective Time
Frame
Choose the desired option for the period.
Start Time
Choose the desired start time using a 24 hr clock.
End Time
Choose the desired end time using a 24 hr clock.
