Servomex 2700 User Manual

Servomex 2700 Quickstart Manual
Servomex 2700 Quickstart Manual
31
Figure 3a
1
2
3
4
5
VIEW
Go to 2
VIEW
Diagnostics
CONFIGURATION
ENTER PASSWORD
0000
Operators Password Go to 4
Supervisor Password Go to 5
Operator Password Functions
CALIBRATE / VIEW
CALIBRATE
MANUAL CALIBRATE Oxygen Low Calibration Calibration
COe High Calibration Procedure
CONFIGURE
Go to 3
Set Up Oxygen
AUTO CALIBRATE Auto COe
Calibrate Oxygen & COe
Start Initiate
Auto Automatic
Calibrate Calibration
VIEW Go to 2
Supervisor Password Functions
CALIBRATE / VIEW
SERVICE / SET UP
Go to 4
Go to 6
Software Version
Oxygen sensor output voltage in mV
Oxygen sensor temperature in
o
C
Oxygen Sensor High Cal Point in mV
Oxygen Sensor Low Cal Point in mV
Combustibles sensor output voltage in mV
Combustibles sensor temperature in
o
C
Combustibles Sensor High Cal Point in mV
Combustibles Sensor Low Cal Point in mV
Sensor Head temperature in
o
C (if connected)
Calibration
Procedure
History
Alarm History
Fault History

Servomex 2700 Specifications

General

Technology	Paramagnetic
Measurement Range	0-100% O2
Outputs	4-20 mA, RS232/RS485
Power Supply	24 VDC or 100-240 VAC
Operating Temperature	0 to 50°C (32 to 122°F)
