Shipping the Analyzer DF-150E 59
13 Shipping the Analyzer
If it becomes necessary to ship the analyzer for service contact your local
Servomex Business Center to obtain a Return Material Authorization (RMA)
number.
Be sure to mark the Return Material Authorization number on the outside of
the shipping carton and on the packing list.
CAUTION
Do not ship the analyzer with liquid in the sensor. Serious damage
can result and the warranty will be voided.
NOTE
The analyzer should be carefully packed in its original packing
materials if possible.
13.1Draining the Sensor
Remove the Sensor
1. Open the front door.
2. Turn power off.
3. Disconnect the electrical cable that runs to the sensor.
4. Loosen the two, knurled thumb screws in front of the sensor.
5. Remove the bulkhead nut from the inlet gas connection on the rear of the
analyzer.
6. If the analyzer is equipped with the stainless steel outlet tubing option,
remove the nut from the outlet bulkhead fitting.
7. Carefully slide the sensor out of the analyzer a few inches.
8. Remove the quick disconnect at the top of the flowmeter. (Skip this step if
the analyzer is equipped with the stainless steel outlet tubing option.)
9. Finish removing the sensor from the cabinet.
10. Carefully un-screw the lid from the sensor.
11. Tip the sensor, carefully capture the liquid, and dispose of it appropriately.
12. Rinse sensor with distilled or de-ionized water.
