7.0 OPERATION
42
7.6.8 Ethernet configuration 2
Press F3 from the first page of the Ethernet configuration 1 menu to access the second page.
FIGURE 28: ETHERNET CONFIGURATION 2 PAGE with DCHP on
If the analyzer is connected to the Internet via a DHCP server, the network router assigns a
TCP/IP address automatically to the analyzer. For this to happen, the DHCP option must be
enabled in the analyzer. To do this, press F1 in this menu in order to set the DHCP to “Yes”. This
corresponds to the easiest way to connect the analyzer to the network because the router manages
the Ethernet connectivity automatically. All the useful information is then displayed in the
Ethernet page of the DIAGNOSTIC MENU.
If the network does not have the DHCP option, a TCP/IP address must be entered manually in the
analyzer. To do this, first turn off the DHCP option by pressing F1 in order to see “No” next to
“DHCP Enabled?”. The menu will look like that:
FIGURE 29: ETHERNET CONFIGURATION 2 PAGE with DHCP off
To set the IP address and the other parameters related to the Ethernet connectivity, press F2.
FIGURE 30: IP PARAMETERS
<<<ETHERNET CONFIGURATION 2>>>
F1:DHCP Enabled?(Yes/No):Yes
F3:NEXT F
4:RET
<<<ETHERNET CONFIGURATION 2>>>
F1:DHCP Enabled?(Yes/No):Yes
F3:NEXT F4:RET
<<<IP PARAMETERS>>>
F1:Local IP:192.167.0.5
F2:Mask: 255.255.255.0
F3:Gateway:192.16
7.0.1 F4:RET
