User Manual SERVOPRO Plasma Trace N
2
Analyzer
7.0 OPERATION
7.0 OPERATION
All analyzer functions are controlled through different menu options. The following figures in
this section show the overall menu structure. You must become familiar with it.
At power on, the analyzer displays the MAIN MENU.
FIGURE 1: MAIN MENU
The MAIN MENU is shown in figure 1.
The following pages give a complete description of each menu and sub-menu.
Note the screen displays at the bottom right the software version programmed into the analyzer.
7.1 Configuration
Pressing F1 from the MAIN MENU will bring you to the CONFIGURATION MENU.
The CONFIGURATION MENU prompts you to enter three different parameters:
1. You have to decide whether or not to use "auto ranging". Choosing F1 "yes" allows the
analyzer to "switch" automatically between the three possible ranges (0 - 1 ppm, 0 - 10 ppm,
0 - 100 ppm). F1 "toggles" the selection between "yes" and "no".
FIGURE 2: CONFIGURATION MENU
2. Desired sample flow: you enter your desired sample flow value simply by using the number
keys and confirming your value with the "E" key for enter. The allowed numeric value for the
flow is any integer number between 0 and 200. The flow unit is cc/m.
The new input value becomes immediately active and the flow valve will react accordingly.
KONTROL ANALYTIK K2001
TRACE N2 ANALYZER
MAIN MENU
F1:Configuration F3:Diagnostic
F2:Calibration F4:Run V1.0
<<CONFIGURATION MENU>> F3:NEXT
F1:Automatic ranging? (Yes/No):YES
Sample flow set point(0-200CC):25
F2:Analog output (Hld/Trk):HOLD
