2.1 Entering Zero and span gas values
From the main menu, press F2 to enter the calibration menus of the analyzer.
FIG 1: ANALYZER MAIN MENU
This will bring you to the CALIBRATION MODE SELECTION MENU as shown below. For the moment, proceed to the
CALIBRATION MAIN MENU by pressing F3.
FIG 2: CALIBRATION MODE SELECTION MENU
FIG 3: CALIBRATION MAIN MENU
From the CALIBRATION MAIN MENU, pressing F1 will enable you to enter the zero gas value.
FIG 4: SETTING THE ZERO GAS VALUE
KONTROL ANALYTIK
SERVOPRO CHROMA
TRACE N2
ANALYZER
MAIN MENU
F1: Configuration F3: Diagnostic
F2: Calibration F4: Run
<<CALIBRATION MENU>>
F1:Zero F2:Span
F3:Calibrate F4:RET
<<CALIBRATION MENU>>
Input ZERO value: 0.00
Actual Value:0.00
Value must be in PPM F4:RET
<<CALIBRAT
ION MENU>>
F1:Calibration Mode: MANUAL
F2:ACTUAL GAS: SAMPLE
F3:NEXT F4:RET
