7.0 OPERATION
Contact your network administrator to set-up this aspect of the analyzer. You must first know the
Gateway of your network. Set it by pressing F3. Then, enter a value of 1 to 3 digits and press E
(enter). Enter the second value of 1 to 3 digits and press E. Enter the third value of 1 to 3 digits
and press E. Finally enter the fourth value of 1 to 3 digits and press E. The Gateway is then
updated. Do the same to change the Mask to the value given to you by your network
administrator by first pressing F2. The Mask is then updated. The Local IP is the address of the
analyzer that is used in your browser to remotely access the analyzer. It generally begins by the
three first values of the Gateway. In general, only the last value (the fourth one) is not equal to
the last value of the Gateway. When everything is set, exit this menu with F4. All the information
is then displayed in the DIAGNOSTIC MENU.
7.6.9 Averaging Number
FIGURE 31: AVERAGING NUMBER
Minimum: 1
Maximum: 25
Resolution: 1
The software may execute a moving average on the calculated ppm value. This will also affect
the response time of the system. The software uses this parameter to determine the number of
sample PPM values that are used in its moving average sub-routine. The number of samples
ranges from 1 to 25. When entering 1, there is no moving average.
For example, in a 5 point moving average filter, the displayed actual process valve will be:
Ppm = p (1) + p (2) + p (3) + p (4) + p (5)
5
Where p (5) is the new measure done and p (1) to p (4) are the four previous ones.
Averaging:3
Actual:1
To Next Page
