7.0 OPERATION
7.3.2 Ethernet info
FIGURE 12: DIAGNOSTIC MENU
This menu is accessible by pressing F3 from the verification page of the 4-20 mA outputs. It
shows different information concerning the Ethernet connection of the analyzer. The TCP/IP
address of the analyzer is displayed in front of “IP” and can be used to control the analyzer from
the Internet and through a simple network. Simply enter, for example, http://192.168.0.111 in
your web browser to see exactly what is currently displayed on the analyzer screen. Use the
computer mouse to click on the keyboard displayed in your browser in order to control the
analyzer normally through the network. The MAC address, the mask and the gateway can be
pertinent information for your network administrator. The MAC address can’t be changed. It is a
hardware characteristic set by Servomex. But to configure the mask, the gateway or change the
Ethernet password, go to the Ethernet pages of the HIDDEN MENU. Refer to the WEB
INTERFACE section for a connectivity procedure.
7.3.3 Serial number
FIGURE 13: SERIAL NUMBER MENU
This menu is accessible by pressing F3 from the Ethernet page. It displays the analyzer serial
number, which corresponds to the one written at the back of the analyzer. This can be useful if
the back of the analyzer is not accessible.
7.4 Run
Most of the time, you will be in this mode, which displayed the following screen that is
accessible by pressing F4 from the MAIN MENU.
<<ETHERNET INFO>> F3:NEXT
IP : 192.168.0.111 MAC: 210200200000
Mask : 255.255.255.0
Gateway : 192.168.0.1 F4:RET
<<SERIAL NUMBER>>
Serial Number:0
F4:RET
